As we work with our new products, it’s not uncommon for us to find possible issues that we don’t see documented elsewhere on the internet. When that happens, we work hard to find a solution or workaround, and post it to this blog!
Before moving Pepper around, make sure that:
1. The floor is flat, dry and there is no rug or a thick carper on the way that could cause the robot to fall.
2. There is at least 120 cm of free space around the robot.
3. You keep Pepper away from steps.
Here are some things to try if your Ozobot robot ignores the color coded instructions:
1. Make sure your lines are the right size.
In order to make the Ozobot recognize the line,
it should be about 5 mm wide.
2. Make sure your lines are consistent.
If the line gets wider or thinner,
Ozobot may loose the line and stop its motion.
3. Make sure your turns are curved gracefully.
If the continuation of the line is in parallel and too close,
the Ozobot robot may see it as the same line
and won't be able to make the turn.
4. Make sure you don't have sharp curves.
5. Make sure your color coded sequence is positioned correctly.
The sequence should be surrounded by
Black lines longer than 2 cm in length.
All colored components of the sequence should be
the same size and length,
without any white space in between or overlapping colors.
6. Make sure the coded sequence colors you are using are not too dark or light.
7. Make sure the sequence is at least 5mm wide
and no longer than 6 mm in length for a single color.
8. Make sure your color coded sequence is well seen by the robot.
Keep codes on straight lines away from the corners,
away from intersections,
and at least 2.5 cm apart from each other.
9. Make sure you are using the correct markers
10. Make sure your robot is fully charged.
If Ozobot blinks red, then the battery needs to be charged.
11. Make sure your Ozobot robot is calibrated.
12. Make sure your Ozobot robot is clean to allow his sensors a good visibility.
Dust or grease can get into Ozobot Bit’s drive train and affect its movement.
It is extremely important to calibrate the Ozobot robot every time you begin playing, when light conditions change and whenever you change your playing surface.
Ozobot’s infrared sensors (also known as its "eyes") are highly sensitive to surrounding light.
As a result, changing paper or moving closer to a window affects Ozobot’s ability to follow lines and read color codes.
Calibration orients Ozobot to the surrounding light and surface.
There are two methods to calibrate the Ozobot robot.
In order to create your own playground for Ozobot, you will need:
* A white sheet of paper;
* Thick markers: Black, Blue, Red and Green.
